Precautions for moisture-proofing industrial control computers in damp environments

Essential Tips for Protecting Industrial Control Computers in Humid Environments

Industrial control computers (ICCs) are vital for automation and process control in sectors like manufacturing, energy, and transportation. However, operating in humid environments poses significant risks, including corrosion, short circuits, and component failure. Implementing effective moisture prevention strategies is crucial to ensure reliability and longevity. Here are practical measures to safeguard ICCs in damp conditions.

Environmental Control and Sealing

Controlling ambient humidity is the first step in preventing moisture damage. Ideally, ICCs should be installed in climate-controlled rooms where humidity levels are maintained between 40% and 60%. In areas where this isn’t feasible, using dehumidifiers can help reduce excess moisture in the air. For outdoor or semi-outdoor installations, consider enclosing ICCs in weatherproof cabinets with gaskets to seal out moisture.

When selecting cabinets, ensure they are made of corrosion-resistant materials like stainless steel or aluminum. The cabinet design should include proper ventilation with filtered vents to allow airflow while preventing water ingress. Additionally, position ICCs slightly elevated above the floor to avoid contact with standing water in case of flooding or spills.

For ICCs installed in areas prone to condensation, such as cold rooms or near cooling systems, use thermal insulation materials to minimize temperature differentials between the device and its surroundings. This reduces the likelihood of condensation forming on internal components.

Component Protection and Maintenance

Sensitive electronic components within ICCs are highly vulnerable to moisture-induced corrosion. To protect these components, apply conformal coatings to printed circuit boards (PCBs). Conformal coatings are thin, protective layers that shield PCBs from moisture, dust, and chemicals. They are available in various formulations, including acrylic, silicone, and urethane, each offering different levels of protection and flexibility.

Regularly inspect ICCs for signs of corrosion, especially on connectors, terminals, and exposed metal surfaces. Corrosion often appears as greenish or whitish deposits and can lead to poor electrical connections or complete failure. If corrosion is detected, clean affected areas with a soft brush and a mild solvent, then apply a corrosion inhibitor to prevent recurrence.

Another critical maintenance task is checking and replacing desiccant packs. Desiccants are moisture-absorbing materials placed inside ICC enclosures to reduce humidity levels. Over time, desiccants become saturated and lose their effectiveness. Replace them according to the manufacturer’s recommendations or when they change color (indicating saturation).

Power Management and Electrical Safety

Moisture increases the risk of electrical shorts and arc faults, which can damage ICCs and pose safety hazards. To mitigate these risks, ensure all electrical connections are tight and free of corrosion. Loose or corroded connections create resistance, generating heat that can ignite flammable materials or cause component failure.

Implement ground fault circuit interrupters (GFCIs) in power supplies to ICCs. GFCIs detect imbalances in electrical current caused by moisture-induced leakage and automatically cut off power to prevent shocks or fires. Additionally, use surge protectors to safeguard ICCs from voltage spikes, which can occur due to moisture-related electrical issues.

When powering down ICCs for maintenance or storage, follow proper shutdown procedures to avoid sudden power interruptions that could damage components. If ICCs will be inactive for extended periods, store them in a dry, temperature-controlled environment with desiccant packs to prevent moisture buildup.

Monitoring and Early Detection Systems

Proactive monitoring is essential for identifying moisture-related issues before they escalate. Install humidity sensors inside ICC enclosures to continuously track moisture levels. Set up alerts to notify operators when humidity exceeds safe thresholds, allowing them to take corrective actions, such as activating dehumidifiers or inspecting for leaks.

In addition to humidity monitoring, use thermal imaging cameras to detect abnormal heat patterns, which may indicate moisture-induced shorts or component overheating. Regularly scan ICCs for hot spots, especially around connectors and power supplies, and investigate any anomalies promptly.

Implement a preventive maintenance schedule that includes routine checks for moisture damage, corrosion, and electrical issues. Document all findings and repairs to track the health of ICCs over time. By establishing a comprehensive monitoring and maintenance program, facilities can minimize downtime and extend the lifespan of their industrial control systems.
