Steps for cleaning industrial control computers before they are idle for a long time

Pre-Long-Term Storage Cleaning Procedures for Industrial Computers

When industrial computers are set to remain idle for extended periods, improper handling can lead to performance degradation, component damage, or even complete failure upon reactivation. A systematic cleaning and preservation process is essential to maintain equipment integrity. Below is a detailed guide covering critical steps and precautions.

Power Disconnection and Safety Precautions

Before initiating any cleaning procedures, ensure the industrial computer is fully powered down and disconnected from all external power sources, including AC mains and battery backups. This prevents electrical shock risks and avoids accidental activation during maintenance. For devices with internal batteries, remove or disable them to prevent leakage or corrosion. Additionally, wear anti-static wristbands and use grounded workstations to mitigate electrostatic discharge (ESD) risks, which can damage sensitive electronic components.

External Surface Cleaning

Dust and Contaminant Removal

Use soft, lint-free microfiber cloths or anti-static brushes to gently wipe down the computer’s exterior housing, including vents, ports, and seams. Avoid abrasive materials like paper towels or rough sponges, which may scratch surfaces or leave residue. For stubborn grime, lightly dampen the cloth with distilled water or isopropyl alcohol (IPA) solution (concentration ≤70%) and wipe in a single direction to prevent smearing. Ensure no liquid enters internal compartments during this process.

Ventilation System Maintenance

Clean cooling fans and heat sinks using compressed air or a low-power vacuum cleaner with a soft brush attachment. Hold the fan blades stationary with a toothpick or plastic tool while blowing air to prevent over-spinning, which could damage bearings. For heavily clogged heatsinks, carefully disassemble the cooling module (if accessible) and use a soft-bristled brush to dislodge dust from fins. Reassemble components securely after cleaning.

Internal Component Cleaning

Access Panel Removal and Component Inspection

Refer to the manufacturer’s service manual to locate and remove access panels covering the motherboard, expansion slots, and storage drives. Before proceeding, document the layout of cables and components using photographs or labels to simplify reassembly. Inspect for visible signs of corrosion, moisture damage, or pest infestation (e.g., insect nests or rodent droppings). If contamination is detected, isolate the device and consult a professional technician.

Motherboard and Circuit Board Care

Use a can of compressed air to blow dust from motherboard surfaces, paying close attention to areas around CPU sockets, RAM slots, and PCIe connectors. For finer particles trapped in crevices, employ a soft-bristled brush with gentle strokes. Avoid touching circuit traces or solder joints directly, as oils from skin can accelerate oxidation. If necessary, lightly dampen a brush with IPA solution (≤70%) to clean non-conductive areas, ensuring complete evaporation before reassembly.

Storage Drive Preservation

For solid-state drives (SSDs) and hard disk drives (HDDs), avoid disassembling the enclosures unless trained to do so. Instead, wipe external surfaces with a dry cloth and store drives in anti-static bags with desiccant packs to absorb moisture. If the industrial computer uses removable storage media (e.g., CFast cards or SD cards), eject them and store separately in labeled protective cases.

Preservation Treatments for Long-Term Storage

Corrosion Inhibition

Apply a thin, even layer of non-conductive corrosion inhibitor spray to metal surfaces, including chassis interiors, connector pins, and screw heads. Focus on areas prone to humidity exposure, such as I/O ports and expansion slots. Allow the coating to dry completely (typically 10–15 minutes) before closing access panels.

Desiccant Placement

Insert silica gel packets or other desiccants into the computer’s enclosure to maintain a low-humidity environment. Secure them away from moving parts and heat sources using non-conductive tape or cable ties. Replace desiccants every 6–12 months, depending on storage conditions.

Sealing and Environmental Control

If possible, store the industrial computer in a climate-controlled room with stable temperature (15–25°C) and humidity (30–60% RH). For outdoor or uncontrolled environments, use heavy-duty plastic storage containers with airtight seals. Line the interior with anti-static foam or bubble wrap to cushion components and prevent physical damage during transportation or handling.

Final Checks and Documentation

Before sealing the storage container, perform a visual inspection to confirm all access panels are securely fastened, cables are neatly routed, and desiccants are properly positioned. Record the cleaning date, storage location, and any observed issues in a maintenance log. This documentation will streamline future reactivation procedures and help track the equipment’s service history.
